Hikvision DS-7324HGHI-SH-SN - DVR 24 Entrées Vidéo Turbo HD H264 4 Interfaces S

Chargement...

-21%

DVR 24 Entrées Vidéo Turbo HD H264 4 Interfaces S DS-7324HGHI-SH-SN

Quantité

Ajouter au panier

Ajouter à ma sélection

Prix Normal : 5 040,00 Dh TTC

Prix :4 200,00 Dh TTC

Prix Promo : 3 967,20 Dh TTC

Hors Taxe : 3 306,00 Dh HT

Economie : 178,80 Dh - 21%

HIKVISION DVR 24 Entrées Vidéo Turbo HD H264, sorties VGA/HDMI , 4 interfaces S

Disponibilité : En Stock

Evaluation :

Evaluer ce produit.

Description
Avis des clients

Caractéristiques Techniques

Video/Audio Input

Audio Input: 4-ch
Video Compression: H.264

Analog and HD-TVI video input: 32-ch, BNC interface (1.0Vp-p, 75 Ω)
Supported camera types: 720p/25Hz, 720p/30Hz, 720p/50Hz, 720p/60Hz, 1080p/25Hz, 1080p/30Hz, CVBS
IP Video Input: 8-ch (up to 32-ch) Up to 2MP resolution
Video Input Interface: BNC (1.0 Vp-p, 75Ω)
Audio Compression: G.711u
Audio Input Interface: RCA (2.0 Vp-p, 1 kΩ)
Two-way Audio: 1-ch RCA(2.0Vp-p, 1kΩ)

Video/Audio Output

HDMI/VGA Output: 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
Recording resolution: 1080p/720p/VGA/WD1/4CIF/CIF
Frame Rate: Main stream:
1080p@12fps;
720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps;
CIF/QCIF/QVGA@25fps (P)/30fps (N)
Video Bit Rate: 32 Kbps-6 Mbps
Stream Type: Video/Video&Audio

Audio Output: 1-ch RCA(Linear, 1kΩ)
Audio Bit Rate: 64kbps
Dual Stream: Support
Playback Resolution: 1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF
Synchronous Playback: 32-ch

Network management

Remote connections: 128
Network protocols: TCP/IP, PPPoE, DHCP, EZVIZ Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI,
UPnP., HTTPS

Hard Disk Driver

Interface Type: 4 SATA interfaces for 4 HDDs; 1 eSATA interface
Capacity: Up to 6 TB capacity for each disk

External Interface

Network Interface: 1; 10M / 100M / 1000M self-adaptive Ethernet interface

USB Interface: | 3 USB2.0 interfaces
Serial Interface: 1RS-485 interface, 1 RS-232 interface, 1 RS-485 keyboard interface
Alarm Input: 16-ch
Alarm Output: 4-ch

General

Power Supply: 100 ~ 240VAC, 47 ~ 63HZ
Consumption: ≤ 65W
Working Temperature: -10 oC ~+55 oC (14 oF ~ 131 oF)
Working Humidity: 10% ~ 90%
Chassis: 19-inch rack-mounted 1.5U chassis
Dimensions: 445 × 390 × 70 mm (17.5 × 15.3 × 2.7 inch)
Weight: ≤5Kg (11.0lb)
